SB700U-11:SE3207 SMA America 6-11
Status Messages on the Display
The Sunny Boy 700U is optionally equipped with the „Sunny Display“ LCD in the
lid.
Betrieb
Operation
Erdschluss
Earth Fault
Störung
Failure
Photovoltaik-Stringwechselrichter
Photovoltaic string inverter
E-today 3.86kWh
Mode MPP
Be
Op
Er
Ea
Stö
Fa
k-Stringwechselrichter
c string inverter
E-today 3.86kWh
Mode MPP
Figure 6-2 Display of the Sunny Boy 700U
Activation of the Background Illumination
The background illumination is activated by slightly knocking on the lid. Knocking
once more activates the next message on the display.
The background illumination is automatically deactivated after 2 minutes.
Messages of the Sunny Display During Initialization
Initialization of the display on the
Sunny Boy 700U
Sunny Boy 700U
WR7xxUxxE
The following messages are displayed during
initialization of the inverter.
Initialization of the display on the
Sunny Boy 700U
BFR Version x.xx
SRR Version x.xx
The installed firmware versions of the control system
(BFR) and the current control processor (SRR) are
displayed after 6 seconds.
