SMA Solar Technology AG 4 Scope of Delivery
Mounting Instructions SCCP-JP-MA-Silence-en-10 11
4 Scope of Delivery
Check the scope of delivery for completeness and any externally visible damage. Contact your distributor if the scope of
delivery is incomplete or damaged.
The scope of delivery comprises two boxes and the rear panel of the inverter. The individual parts included in the delivery
are listed below.
4.1 Scope of DeliveryScope of Delivery - Silencing Baffle
Figure 3: Components included in the scope of delivery of the silencing baffle
Position Quantity Designation
A 1 Silencing baffle rear panel, including ventilation plate
B 1 Silencing baffle lid
C 1 Rain protection
D 1 Touch-up stick RAL 7035
E 1 OKS
®
250 allround paste
F 15 Pan head flange screw
G 9 Cylinder head screw
H 7 Contact washer
I 14 Washer
K 10 Hexagon nut
