HEIDENHAIN TNC 620 7
TNC Model, Sof
tw
a
re
and F
eat
ur
es
Software options
The TNC 620 features various software options that can be enabled by
your machine tool builder. Each option is to be enabled separately and
contains the following respective functions:
Hardware options
Additional axis for 4 axes and open-loop spindle
Additional axis for 5 axes and open-loop spindle
Software option 1 (option number #08)
Cylinder surface interpolation (Cycles 27, 28 and 29)
Feed rate in mm/min for rotary axes: M116
Tilting the machining plane (plane functions, Cycle 19 and 3-D ROT
soft key in the Manual Operation mode)
Circle in 3 axes with tilted working plane
Software option 2 (option number #09)
Block processing time 1.5 ms instead of 6 ms
5-axis interpolation
3-D machining:
„ M128: Maintaining the position of the tool tip when positioning
with swivel axes (TCPM)
„ M144: Compensating the machine’s kinematics configuration for
ACTUAL/NOMINAL positions at end of block
„ Additional parameters for finishing/roughing and tolerance
for rotary axes
in Cycle 32 (G62)
„ LN blocks (3-D compensation)
Touch probe function (option number #17)
Touch-probe cycles
„ Compensation of tool misalignment in manual mode
„ Compensation of tool misalignment in automatic mode
„ Datum setting in manual mode
„ Datum setting in automatic mode
„ Automatic workpiece measurement
„ Automatic tool measurement
