8964ENC/-FS — Instruction Manual 63
Specifications
Performance
Quantization 10-bit
Accuracy 9.2-bit EDH detection
Output phasing Full frame with frame synchronizer firmware
Cable length 300M of 1694A cable
Environmental
Frame temperature range
Refer to the Gecko Frames or GeckoFlex Frames 8900FX/FF/FFN Signal Process-
ing Systems Instruction Manual at
www.grassvalley.com/docs/modular
Operating humidity range
Non-operating temperature
Mechanical
Frame type Gecko 8900 Video or GeckoFlex with 8900V-R rear module
Rear Retainer clip screw torque (GeckoFlex frame) 4-5 inch-lb./0.45-0.6Nm
Power Requirements
Supply voltage +12V
Power consumption < 8.5 W (2 A fast blow fuse)
Table 7. 8964ENC/-FS Specifications
Parameter Value
