8960ENC—Instruction Manual

25

Configuration

Ban

k 2

- 2nd LED On

0

Video

Reference

Lock Source – Selecting Video forces delay mode even if a reference
signal is present

1

Increase

Decrease

Fine delay adjustment

2

Increase

Decrease

Horizontal Delay

c

– Provides synchronizer delay adjustment in clock

increments and line increments accordingly.t

3

Increase

Decrease

Vertical Delay

3

– Provides synchronizer delay adjustment in clock

increments and line increments accordingly

4

Manual

Auto

Freeze Recognition

3

– Selecting Auto stores the last field in the

frame synchronizer to use if the input video is lost or corrupted.

5

Off On

Freeze Manual

3

– Enables/Disables manual selection of Freeze

Mode according to positions 6&7.

6

Frame

Field

Freeze Mode

3

– Select between Frame and Field.

7

Field 1

Field 2

Freeze Field

3

– Select between Field 1 and Field 2.

8

Last Field

Black

Freeze Signal

3

– Selects the freeze output signal if Auto or manual

freeze is activated.

9

currently not used

A

Enable

Disable

Cross color removal – Enables/Disables the cross-color removing
2D filter.

B

currently not used

C

Colorbar

Linearity

Test Signal – Select between colorbar and linearity signal.

D

Enable

Disable

Test Mode – If Test is selected, the input SDI is replaced with the test
pattern selected in 2:C.

E

Inactive Position

F

On

Off

Adds or removes setup for vertical interval in both fields

a

Grass Valley no longer supports PAL-M in any of its modular products. Although this setting may work in certain applications,

Grass Valley will not warrant that it works or provide support if problems are encountered using this product with PAL-M signals.
This product has not been modified to eliminate support for PAL-M. If this product has been used with PAL-M in the past without
problems, there shouldn’t be any issues using it for the same application. However, it is not recommended that customers use it in
any new PAL-M applications.

b

Inactive if User Adjustments (switch position 5) is set to Calibrated.

c

Inactive if Frame Sync Submodule is not present.

Table 5. Encoder Configuration Functions - (continued)

Function

Switch

Paddle

Switch Up

Paddle

Switch Down

Function Description
