20 8960ENC—Instruction Manual
Configuration
Configuration Summary Table
Table 4 provides a complete summary of the 8960ENC functions and a
comparison of the functionality available with each control type along with
the ranges and default values for each parameter.
Table 4. Summary of Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Function Switch
Bank/Setting
Newton
Control
Panel
Notes/
Conditions
Standard Recognition Auto Auto or Manual
Standard Selection/
Standard Recognition pulldown
1:0 Auto Std
Manual Standard
Selection
525 525 or 625
Standard Selection/
Manual Selection pulldown
1:1 Lines
Manual mode
selected in
Standard Rec-
ognition above.
Output Video Setup Setup Setup or No Setup
Standard Selection/
Output Video Setup pulldown
1:2 FF Setup
525 only
Vertical Interval Setup Off On or Off
Standard Selection/
VI Setup pulldown
2:F VI Setup
Line 21 Setup Off On or Off
Standard Selection/
Line 21 Setup pulldown
1:D L21Setup
Line 22 Setup Off On or Off
Standard Selection/
Line 22 Setup pulldown
1:E L22Setup
NTSC or PAL-M
selection
NTSC NTSC or PAL-M
a
Standard Selection/
NTSC/PAL-M Select pulldown
1:3 525 Std
Standards Selection
Controls Type
Numeric Numeric
b
or Slider
Standard Selection/
Controls Type pulldown
N/A N/A Web page only
Output Video Level 97.09%
41.5 to 171.55%
2
(0.51% steps)
Standard Selection/
Output Video Level (% 1Vpp)
Slider or arrow controls
1:4 Video
User Adjustments Calibrate Calibrate or User
Levels/
User Adjustments pulldown
1:5 Levels
Levels Control Type Numeric Numeric 2 or Slider
Levels/
Controls Type pulldown
N/A N/A Web page only
Luma Level adjustment
to set luma gain
99.74%
89.5 to109.9% 2
(0.08% steps)
Levels/
Luma Level (% White)
Luma Level slider
or arrow controls
1:6 Luma
User mode
selected in User
Adjustments
above
Chroma Level adjust-
ment to set chroma gain
99.52%
88 to 110.95% 2
(0.09% steps)
Levels/
Chroma Level (% saturation)
Chroma Level slider
or arrow controls
1:8 Chroma
Hue Level adjustment
(525 only)
0 degrees
0 to 358.05 degrees 2
(0.35 degree steps)
Levels/
Hue (degrees)
Hue Level slider
or arrow controls
1:9 Hue
Black Level adjustment 7.54%
-14.22 to 21.48%
2
(0.34% steps)
Levels/
Black Level (% White)
Black Level slider or arrow
controls
1:7 Black
Lock Source selection Reference Video or Reference
Timing/
Lock Source pulldown
2:0 Lock To
