Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
Thank you for purchasing the Airaid Intake System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST weekdays for questions regarding fit or instructions
that are not clear to you. Your Airaid Intake System was carefully inspected and packaged. Check that no parts are missing, or were damaged during shipping. If any parts are
missing, contact Airaid. The air filter element is protected from direct exposure to water and debris; care should be taken not to drive through deep water. WATER INGESTION
IS THE DRIVERS RESPONSIBILITY! The air filter is reusable and should be cleaned periodically.
13. Install the Quick Fit assembly in the bottom of the
stock air box by sliding the four tabs on the back
into the slots on the airbox, once installed, re-hook
the two latches. Next, install the speed clamp over
the breather hose and connect it to the Quick Fit
assembly as shown.
10. Carefully twist and remove the temperature sensor
from the bottom of the resonator, and then remove
the resonator from the vehicle.
11. Assemble the two pieces of the Quick Fit panels as
shown, using the four 6-32 screws, washers, and
nuts, that are provided in the kit.
12. Install the weather strip on the top of the Quick
Fit assembly. (Hint: start at one end, and go to-
wards the other end, don’t start in the middle.)
REV.10.15.13
14. Install the hump hose and two #60 hose clamps on
the Quick Fit assembly. Do not tighten the clamps
at this time.
15. Install the coupler and two #60 hose clamps on
the throttle body as shown. Do not tighten the
clamps at this time. Secure the breather hose to
the air conditioner line using the supplied zip tie.
FILTER IDENTIFICATION
700-458 Airaid Oiled Media 701-458 Airaid SynthaMax Dry Media - Red
702-458 Airaid SynthaMax Dry Media - Black 703-458 Airaid SynthaMax Dry Media - Blue
16. Install the supplied grommet into the hole in the
back of the tube.
17. Carefully install the temperature sensor into the grom-
met. Make sure it goes all the way in.
First
Second
18. Carefully install the end of the tube into the hump
hose, and then into the coupler on the throttle
body as shown. Adjust the tube as needed, and
tighten the four hose clamps.
19. Install the Airaid Premium Filter on the Quick Fit
assembly as shown, and tighten the hose clamp.
20. Realign the engine cover with the grommets on the
engine, and push down firmly to reseat the cover.
21. Reinstall the oil fill plug.
22. Recheck your work, make sure there is no foreign
material in the intake, double check all hose
clamps, screws and nuts for tightness.
23. Reconnect the negative battery cable.
For your Oiled media filter we suggest
using the AIRAID Filter Tune-Up Kit!
Synthamax Air Filters do not require oil. Service air
filter as needed by cleaning with common non-
petroleum all-purpose household cleaner and water.
Simple Green®, Formula 409® or equivalent works
great. Apply cleaner to outside of air filter and allow
to soak. Then flush filter clean from the inside out
with a garden hose and repeat steps if necessary. Do
not apply high pressure water or air to clean filter.
Allow filter to air dry and reinstall.
