Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
REV.11.4.13
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
10. Install the nylon fitting (#15) into the air
filter adapter as shown.
14. Install the hump hose (#7) and coupler (#8)
onto the Airaid Intake Tube using four #60 hose
clamps (#18). The coupler is positioned on the
throttle body end and the hump hose is posi-
tioned on the air filter adapter end of the tube.
12. Remove the factory breather hose. Connect
one end of the ¾” x 25” hose (#5) to the nylon
fitting and the other to the oil fill nipple as
shown. Secure each end using one #24 Speed
Clamp (#16). Adjust the nylon fitting down-
ward to clear the Airaid Intake Tube assembly.
13. Install the rubber grommet (#17) and factory
air temperature sensor into the Airaid Intake
Tube (#6).
18. Double check your work!
Make sure there is no foreign material in
the intake path. Make sure all clamps,
hoses, bolts, and screws are tight.
19. Reconnect the negative bat-
tery cable!
17. Install the Airaid Premium Filter (#1) onto the
end of the air filter adapter. Install the weather
strip (#9) onto the top of the Airaid Quick Fit
Panels. (Note: start from one end and work your
way around to insure proper alignment of the
weather strip.)
16. Reconnect the factory air temperature sen-
sor wiring harness to the sensor.
15. Install the Airaid Intake Tube assembly onto
the engine with the hump hose end towards the
air filter adapter. Adjust the assembly for fit and
then tighten the four hose clamps.
11. Install the Quick Fit Panels onto the top of
the factory air box base. Relatch the factory
clips onto the tabs on the Quick Fit Panels.
Thank you for purchasing the Airaid Intake System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST weekdays for questions
regarding fit or instructions that are not clear to you. Your Airaid Intake System was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, contact Airaid. The air filter element is protected from direct exposure to wa-
ter and debris; care should be taken not to drive through deep water. WATER INGESTION IS THE DRIVERS RESPONSIBILITY! The air filter
is reusable and should be cleaned periodically.
FILTER IDENTIFICATION
700-450 Airaid Oiled Media 701-450 Airaid SynthaMax Dry Media - Red
702-450 Airaid SynthaMax Dry Media - Black 703-450 Airaid SynthaMax Dry Media - Blue
For your Oiled media filter we
suggest using the AIRAID Filter
Tune-Up Kit!
Synthamax Air Filters do not require oil.
Service air filter as needed by cleaning
with common non-petroleum all-purpose
household cleaner and water. Simple
Green®, Formula 409® or equivalent
works great. Apply cleaner to outside of
air filter and allow to soak. Then flush
filter clean from the inside out with a gar-
den hose and repeat steps if necessary.
Do not apply high pressure water or air
to clean filter. Allow filter to air dry and
reinstall
.
