Airaid 300-139 - Manual

Installation Instructions
For Part Numbers:
300-139 720-128 Airaid Oiled Media Filter
301-139 721-128 SynthaMax Dry Media Filter - Red
302-139 722-128 SynthaMax Dry Media Filter - Black
303-139 723-128 SynthaMax Dry Media Filter - Blue
1994-02 Dodge Ram 2500/3500
5.9L I6 Cummins Diesel
Component Identification
1. Airaid Premium Filter 1
2. Front Panel 1
3. MAF Panel 1
4. Weather Strip 35 ½” 1
5. 6-32 x 5/16” Screw 4
6. 6-32 Nut 4
7. #6 Flat Washer 4
Full color instructions can be viewed on our web site at Airaid.com. Use the Product Search function to find your part number, and click View Details.
I DISCONNECT NEGATIVE (-) BATTERY CABLE
II
Remove Factory Intake Assembly
A) Unclip the factory air box lid.
B) Loosen clamp connecting the factory air box lid to the air intake tube and remove the air box lid and factory air filter
from the vehicle. (Note: leave the factory air box base in place) See Fig#1
III
Airaid Intake System Pre-Installation Assembly
A) Assemble Airaid Quick Fit cool air dam panels using the (4) 6/32 bolts, washers and nuts provided. See Fig#2
IV Airaid Intake System Installation
A) Install the Airaid intake assembly in place of the factory air box. Refer to Fig#3
B) Secure the factory intake tube to the Airaid cool air dam using the factory hose clamp.
C) Mount the Airaid Premium Filter to the tube on the inside of the Airaid cool air dam and tighten the hose clamp. Refer to
Fig#3
D) Install weather strip onto the top ridge of the Airaid cool air dam (Hint: start the install at the top corner of the cold air
dam) Refer to Fig#2 & Fig#3
V
Finishing Up
A) Inspect overall work and check hood clearance.
B) Ensure that no foreign objects are in the intake path!
C) Re-connect negative battery cable.
Fig#1 Fig#2 Fig#3
