Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
REV.11.11.13
16. Double check your work!
Make sure there is no foreign material in
the intake path. Make sure all clamps,
hoses, bolts, and screws are tight.
15. Install the Airaid Premium Filter (#1) onto
the filter adapter, and tighten the hose clamp.
Install the weather strip (#7) onto the Airaid Cold
Air Box. Reconnect the M.A.F. sensor . (Note:
Start from one corner and work your way around
to insure proper alignment of the weather strip.)
14. A.) Install the hump hose end of the Air aid
intake tube assembly onto the filter adapter first.
B.) Slip the coupler end of the tube over the
factory turbocharger inlet. Adjust for fit, and
tighten the hose clamps
A.
.B
16. Reconnect the negative bat-
tery cable!
11. Install the urethane hump hose (#5) and two
#72 hose clamps (#12) onto the large end of the
Airaid intake tube. (Note: Leave hose clamps
loose until final assembly.)
12. Install the urethane coupler (#6) and two #60
hose clamps (#11) onto the small end of the
Airaid intake tube. (Note: Leave hose clamps
loose until final assembly.)
13. Your complete Intake tube assembly should
look like this.
WARNING! If your vehicle has a Vehicle Emission Control Information decal affixed to the factory airbox, a new replacement label must
be obtained and installed in a readily visible position in the engine compartment in order to remain CARB compliant. Failure to do so will prevent
the vehicle from passing a smog check. Replacement labels can be ordered from your local dealership. Regulations state that the VECI label shall
not be affixed to any equipment which is easily detached from the vehicle. Label placement, under the hood on a painted surface is recommended.
Thank you for purchasing the Airaid Intake System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST weekdays for questions
regarding fit or instructions that are not clear to you. Your Airaid Intake System was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, contact Airaid. The air filter element is protected from direct exposure to wa-
ter and debris; care should be taken not to drive through deep water. WATER INGESTION IS THE DRIVERS RESPONSIBILITY! The air filter
is reusable and should be cleaned periodically.
FILTER IDENTIFICATION
720-472 Airaid Oiled Media
721-472 Airaid SynthaMax Dry Media - Red
722-472 Airaid SynthaMax Dry Media - Black 723-472 Airaid SynthaMax Dry Media - Blue
For your Oiled media filter
we suggest using the AIRAID
Filter Tune-Up Kit!
Synthamax Air Filters do not require oil.
Service air filter as needed by cleaning
with common non-petroleum all-purpose
household cleaner and water. Simple
Green®, Formula 409® or equivalent
works great. Apply cleaner to outside of
air filter and allow to soak. Then flush
filter clean from the inside out with a gar-
den hose and repeat steps if necessary.
Do not apply high pressure water or air
to clean filter. Allow filter to air dry and
reinstall
.
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
