Airaid 200-185 User Manual
Page 2
15. Double check your work!
Make sure there is no foreign material in the
intake path. Make sure all clamps, hoses,
bolts, and screws are tight.
16. Reconnect the negative battery
cable!
Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
REV.11.14.13
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
10. Re-install the Mass Air Flow sensor onto
the filter adapter, and tighten the hose clamp.
Make sure the rectangle area where the wiring
connects is pointing straight up.
11. Install the urethane hump hose (#6) on the
Mass Air Flow sensor with two #60 hose clamps
(#15). Next install the coupler (#7) on the throt-
tle body with two #64 hose clamps (#16).
12. Install the Modular Intake Tube into the
hump hose first, and then into the throttle body.
Adjust for fit, and tighten all four hose clamps.
Re-insert the plastic piece from step #3 into the
hole on the bottom of the MIT.
13. Install the Airaid Premium Filter (#1) onto
the filter adapter (#5), and tighten the hose
clamp. Next install the weather strip (#8) onto
the top of the CAD as shown. For ease of in-
stallation start at the fender, and work towards
the radiator.
14. Re-install the beauty cover and bolt removed
in step #1.
WARNING! If your vehicle has a Vehicle Emission Contr ol Infor mation decal affixed to the factor y air -
box, a new replacement label must be obtained and installed in a readily visible position in the engine compart-
ment in order to remain CARB compliant. Failure to do so will prevent the vehicle from passing a smog check.
Replacement labels can be ordered from your local dealership. Regulations state that the VECI label shall not be
affixed to any equipment which is easily detached from the vehicle. Label placement, under the hood on a paint-
ed surface is recommended.
FILTER IDENTIFICATION
700-469 Airaid Oiled Media
701-469 Airaid SynthaMax Dry Media - Red
702-469 Airaid SynthaMax Dry Media - Black 703-469 Airaid SynthaMax Dry Media - Blue
For your Oiled media filter we
suggest using the AIRAID Filter
Tune-Up Kit!
Synthamax Air Filters do not require oil.
Service air filter as needed by cleaning
with common non-petroleum all-purpose
household cleaner and water. Simple
Green®, Formula 409® or equivalent
works great. Apply cleaner to outside of
air filter and allow to soak. Then flush
filter clean from the inside out with a gar-
den hose and repeat steps if necessary.
Do not apply high pressure water or air
to clean filter. Allow filter to air dry and
reinstall
.
Thank you for purchasing the Airaid Intake System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST weekdays for questions
regarding fit or instructions that are not clear to you. Your Airaid Intake System was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, contact Airaid. The air filter element is protected from direct exposure to wa-
ter and debris; care should be taken not to drive through deep water. WATER INGESTION IS THE DRIVERS RESPONSIBILITY! The air filter
is reusable and should be cleaned periodically.
