GNR-3000 System Administrator’s Manual
85
Set PTZ Preset Points
With PTZ devices, you may define a view by where to look (through panning and tilting) and
how close (through zooming) to zoom. Once these views have been saved in NVR server as
preset points, the device can always point to this view upon the event triggering or user ’s
command.
1. Go to Setup page Devices tab, select the device from Device List, and click PTZ tab.
2. By PTZ operation, control the device to point at your desired view, and adjust the zoom
level (if available). In PTZ Preset Point section, click a preset point name field to start
editing the name, then click “+” to set this point. After finishing setting your desired preset
points, click “Apply”. You may review the points you set by clicking “” to go to the point, or
“X” to delete it. You may modify an existing point with following procedure: 1. Select it 2.
Define a new view 3 . Click the “+” to set it 4. Click “Apply” to save it.
3. After the preset points are set, they are available on Live View page PTZ control panel.
Cancel Zoom area
Draw Zoom area
1
Picture-in-Picture area
