GNR-3000 System Administrator’s Manual
Adjustment Attributes
Field Name
Description
Vendor
Vendor is the provider of Protocol. The selectable vendors would vary
depending on different device models. Available vendor types are:
ACTI, DYNACOLOR, PELCO and SONY.
Protocol
Protocol is a set of rules to define the communication format between the
device and controller. Different protocols are provided for selection according to
the Vendor you choose.
Available protocols following their vendors are:
ACTI: [ACTI] / DYNACOLOR: [DYNACOLOR] / PELCO: [PELCOD] [PELCOP]
SONY: [VISCA]
Parity
Parity is the data validation mechanism for analog devices that use serial port
interface to send or receive data. When choosing parity mode other than
"none", the data packets will be validated for possible data losses so that failed
command could be re-sent if necessary. Please refer to the parity setting of the
analog device and choose exactly the same parity setting also in NVR. When
setting up ACTi Zoom, PTZ or Speed Dome cameras using
“ACTi”
protocol, you may ignore the parity setting.
Available parity modes are:
Parity mode name
in NVR
Serial data,
represented by given
amount of bits
Parity mode
(none, odd, even)
Number of stop
bits
8N1
8
N
1
8O1
8
O
1
8E1
8
E
1
8N2
8
N
2
8O2
8
O
2
8E2
8
E
2
7N2
7
N
2
7O2
7
O
2
7E2
7
E
2
Baud rate
Baud rate defines the data speed through serial port interface
– the rate value
represents the number of symbols that can be transmitted within 1 second.
Please refer to the baud rate setting of the analog device and choose exactly
the same baud rate setting also in NVR. When setting up ACTi Zoom, PTZ or
Speed Dome cameras using
“ACTi” protocol, you may ignore the baud
rate setting.
Available baud rates:
2400, 4800, 9600, 19200, 38400, 57600, 115200
