GNR-3000 System Administrator’s Manual

Step 2: Mount the Disk

Mount the disk by locking it with supplied disk screws to the bottom of the tray.

Step 3: Install the Tray

Press on Lock Tab, push the tray into the bay until it stops.

Press on the Hinge Tab until it clicks into place.
