GNR-3000 System Administrator’s Manual

Manage maps:

All the uploaded images are managed under Map Image Manager. On Live View screen, you

may go to  Map Image Manager to view, upload or delete the maps.

Step 6: Add Devices to the Map

Pull a device from Device List to the map.

To remove this device from map:

Click

To move this device:

Left-click on the device icon and drag.

To turn the pointed direction:

Mouse over the viewing angle area, left-click on the

clockwise arrow to turn the direction.
