190

EPSON

S5U1C62000A MANUAL

(S1C60/62 FAMILY ASSEMBLER PACKAGE)

CHAPTER 9: DEBUGGER

bsyn

(break disable)

Function

This command sets the break disable (synchronous) mode. When the PC break, data break, register
break or multi break condition is met with the Evaluation Board CPU state, a pulse is output to the
ICE SYNC pin. However, a break is not generated.

Format

>bsyn

↵

(direct input mode)

Example

>bsyn

↵

Set to break disable (synchronous) mode.

GUI utility

[Option | Mode Setting …] menu item

When this menu item is selected, a dialog box appears for setting break disable mode. Select the
[Break Disable] button in the dialog box. (See the be command.)
