S5U1C62000A MANUAL
EPSON
133
(S1C60/62 FAMILY ASSEMBLER PACKAGE)
CHAPTER 9: DEBUGGER
9.6 Menu
This section outlines the menu bar available with the debugger.
9.6.1 Menu Structure
The menu bar has eight menus, each including frequently-used commands.
9.6.2 [File] Menu
[Load File...]
This menu item reads an object file in the IEEE-695 format into the debugger. It
performs the same function when the lf command is executed.
[Load Option...]
This menu item reads a program or optional HEX file in Intel-HEX format into
the debugger. It performs the same function when the lo command is executed.
[Exit]
This menu item quits the debugger. It performs the same function when the q
command is executed.
9.6.3 [Run] Menu
[Go]
This menu item executes the target program from the address indicated by the
current PC. It performs the same function when the g command is executed.
[Go to Cursor]
This menu item executes the target program from the address indicated by the
current PC to the cursor position in the [Source] window (the address of that
line). It performs the same function when the g command is executed.
Before this menu item can be selected, the [Source] window must be open and
the address line where the program is to break must be clicked. Selecting a break
address by clicking on the address line is valid for only the lines that have actual
code, and is invalid for the source-only lines.
[Go from Reset]
This menu item resets the CPU and then executes the target program from the
program start address (0x100). It performs the same function when the gr command
is executed.
[Step]
This menu item executes one instruction step at the address indicated by the
current PC. It performs the same function when the s command is executed.
[Next]
This menu item executes one instruction step at the address indicated by the
current PC. If the instruction to be executed is call or calz, it is assumed that a
program section until control returns to the next address constitutes one step and
all steps of their subroutines are executed. This menu item performs the same
function when the n command is executed.
[Command File...]
This menu item reads a command file and executes the debug commands written
in that file. It performs the same function when the com command is executed.
[Reset CPU]
This menu item resets the CPU. It performs the same function when the rst
command is executed.
