707054-005 3-31
Chapter 3. Configuring the SCON
IP Host Classes Panel
IP Host Classes LINCS C8.2 Central Control
ASCII Ses
Class Line IP Address or Name Profile Class Name
----- ---- -------------------------- ---------- -------------
01 FET1 142.67.93.112 01 TN3270_HOST
02 FET1 142.67.96.11 00 SCON-22L_MGMT
03 FET1 LPAR19.HOST.ACME.COM 00 LPAR19
04 None _________________________ __ _____________
05 None _________________________ __ _____________
06 None _________________________ __ _____________
07 None _________________________ __ _____________
08 None _________________________ __ _____________
09 None _________________________ __ _____________
10 None _________________________ __ _____________
11 None _________________________ __ _____________
12 None _________________________ __ _____________
13 None _________________________ __ _____________
14 None _________________________ __ _____________
15 None _________________________ __ _____________
16 None _________________________ __ _____________
PF: 1-Menu 7-Back 8-Forw 9-Default 10-Done
The IP Host Classes panel is used to define the host connections that the Telnet and TN3270E
sessions will go to. Assignment of the ASCII Session Profile determines which connections
will use the Telnet definition and which will use the TN3270E definition.
Device Profile 00/Host Assignments LINCS C8.2 Central Control
Profile Name: _______________
Device Type: Display
Power Off Action: None
Session: Host Assignments At Power On
-------- ----------------------------
A 3270 Host A
B IP Host Class: LPAR19
C IP Host Class: TN3270_HOST
D Disable
E Disable
F Disable
G Disable
H Disable
I Disable
J Disable
PF: 1-Menu 3-Def_Dflt 4-Add 5-Delete 7-Back 8-Forw 9-Default 10-Done
The device profile panel allows you to toggle through all of the possible host connections
that have been defined including the Telnet host and TN3270E host connections. In this
