V e l o c i t y D V I E x t e n d e r P r o d u c t M a n u a l , R e v . H , D e c . 2 0 1 4 Page 50
Velocity System-3 RX SEPARATE AUDIO STATUS LEDs
MONITOR
L1 ACTIVE A1 ACTIVE STATUS LED NEW ENHANCEMENT
DON’T CARE NO NO RED FLASH
NOT IN DDC PORT NO YES GREEN FLASH / ORANGE 
NOT IN DDC PORT YES NO ORANGE FLASH / GREEN 
NOT IN DDC PORT YES YES ORANGE
INSTALLED DDC PORT NO YES GREEN FLASH 
INSTALLED DDC PORT YES NO ORANGE FLASH 
INSTALLED DDC PORT YES YES GREEN
Velocity System-3 TX SEPARATE DATA STATUS LEDs
DDC MODE
DVI SOURCE L2 ACTIVE STATUS LED NEW ENHANCEMENT
NOT LOCAL STATIC YES NO RED FLASH
DON’T CARE YES YES GREEN
LOCAL STATIC YES NO ORANGE
DON’T CARE NO DON’T CARE RED FLASH 
Velocity System-3 RX SEPARATE DATA STATUS LEDs
MONITOR
L1 ACTIVE K1 ACTIVE STATUS LED NEW ENHANCEMENT
DON’T CARE NO NO RED FLASH
NOT IN DDC PORT NO YES GREEN FLASH /ORANGE 
NOT IN DDC PORT YES NO ORANGE FLASH / GREEN 
NOT IN DDC PORT YES YES ORANGE
INSTALLED DDC PORT NO YES GREEN FLASH 
INSTALLED DDC PORT YES NO ORANGE FLASH 
INSTALLED DDC PORT YES YES GREEN
HDCP Compliant
Velocity System-3 HDCP Compliant TX STATUS LEDs
DDC MODE
DVI SOURCE L2 ACTIVE STATUS LED NEW ENHANCEMENT
NOT LOCAL STATIC YES NO RED FLASH
DON’T CARE YES YES GREEN
LOCAL STATIC YES NO ORANGE
DON’T CARE NO DON’T CARE RED FLASH 
Velocity System-3 HDCP Compliant RX STATUS LEDs
MONITOR
L1 ACTIVE STATUS LED NEW ENHANCEMENT
DON’T CARE NO RED FLASH
NOT IN DDC PORT YES ORANGE
INSTALLED DDC PORT YES GREEN
