V e l o c i t y D V I E x t e n d e r P r o d u c t M a n u a l , R e v . H , D e c . 2 0 1 4 Page 12
2. 6. Technical Specifications (Systems-3, -6, -33 and -63)
Technical Specifications (Systems-3, -6, -33, -63)
Video Resolution
Vel-3: Any single-link DVI resolution
Vel-6: Any single-link or dual-link DVI resolution
Panel Connections
Transmitter
Video DVI-D (2)
Power 2.5 mm power connector
Fiber Connections ST, SC, LC or Neutrik
®
Receiver
Video DVI-D (2)
Power 2.5 mm power connector
Fiber Connections ST, SC, LC or Neutrik
®
Operating Temperature
and Humidity
0-50 o C (32-122 o F, 5-95% RH, non-condensing)
Storage Temperature -20 to 70 o C (-4 to 158 o F)
Indicators
LEDs on each DVI Extender unit:
Front: Power, Connection Status
Rear: DDC Modes - Local, Remote
Weight
<1 lb. (0.45 kg) each (Vel-3, Vel-6)
4 lb. (1.81 kg) each (Vel-33, Vel-63)
Dimensions See page 30.
Shipping Weight
4 lb. (1.81 kg) pair (Vel-3, Vel-6)
13 lb. (5.89 kg) pair (Vel-33, Vel-63)
Optical Cable
Sys-3 = 2 fibers, Sys-33 = 6 fibers
Sys-6 = 3 fibers, Sys-63 = 9 fibers
(available, not supplied)
Optical Distance
Up to 350 meters using 50/125um, type OM2
Up to 1000 meters using 50/125um, type OM4
Up to 10/40/80 kilometers using 9/125um (Optics available)
Supply Voltage
+5.0 VDC (Vel-3, Vel-6)
90-264 VAC (Vel-33, Vel-63)
Power Consumption
6 watts per unit (Vel-3, Vel-6)
20 watts per unit (Vel-33, Vel-63)
DC Adapter AC/DC adapter, universal input 90-264 VAC (supplied, Vel-3, -6)
DB9 to RJ45 Adapters
With AV+ models only:
DB9M to RJ45 (ADP-000019-R)
DB9F to RJ45 (ADP-000025-R)
Copper Video Cables
CBL000009-002MR Single-link DVI-D Male to Male, 2 meters
1 each, Vel-3 3 each, Vel-33
CBL000023-002MR Dual-link DVI-D Male to Male, 2 meters
1 each, Vel-6 3 each, Vel-63
Compliance Approvals for US, Canada, and European Union
Warranty
12 months from date of shipment.
Extended warranties available at time of purchase.
