Flash Test.
Measuring Range: 0.3 - 6mA
Accuracy: +8% +60uA
Test Voltage: 1.5KVrms for Class I operation
3.0KVrms for Class ll operation
Pass Range: 3, 5mA selectable
Load Test.
Test Voltage: 230V for 13A style plugs
Test Current: 230mA at 230V short circuit
Operations Test
Measuring Range : 0 - 3.3kVA
Accuracy: +5% +130VA
Pass Range: 500W, 1 kW, 2kW, and 3.3kW (this is
predetermined by the power handling
capabilities of the instrument).
Leakage Test.
Measuring Range: 0.5 - 9.9mA
Accuracy: + 10% +60uA
Test Voltage: Mains supply
Pass Range: 3.50mA Class I 0.75mA Class ll
On auto and manual
IEC Lead Test.
Polarity Check
L-L 0.5A, 6V
N-N 0.5A, 6V
Pass Range:
Pass or Fail
GENERAL
Dimensions: 410mm x 370mm x 160mm
Weight: 10kg
Physical Environment: Operating Temperature Range 0°C to 40°C
Relative Humidity max 80% up to 31°C
Decreasing to 50% at 40°C
For indoor use only
Altitude < 2000 M
Electrical Environment: Installation Category ll
Pollution Degree 2
Construction Category: IEC1010
PAT 2000i Portable Appliance Tester
