10
Polarity Selection - Full Test Repeat Selection
0 = Polarity test excluded
1 = Polarity test included
2 = Polarity test excluded and repeat full test
3 = Polarity test included and repeat full test
4 - 9 = N/A
For compatibility the PAT2000i will accept PAT2000 codes, but note that the PAT2000i
codes are the preferred ones and should be used for all new tests.
The PAT2000 codes are as follows:
Digit
Value and Test
1
1 = NO TEST (must be 1)
2
0 = visual check omitted
1 = visual check included
3
0 = 230V socket
1 = 110V socket
4
0 = Class ll
1 = Class I 0.1
Ω
2 = Class I 0.5
Ω
3 = Class I 2.0
Ω
4 = Class I 0.1
Ω
up to 3 tests
5 = Class I 0.5
Ω
up to 3 tests
5
0 = insulation omitted
1 = 7M
Ω
pass level
2 = 2M
Ω
pass level
3 = 4M
Ω
pass level
4 = 7M
Ω
pass level up to 3 tests
5 = 2M
Ω
pass level up to 3 tests
6 = 4M
Ω
pass level up to 3 tests
7 = 1 M
Ω
pass level
8 = 0.5M
Ω
pass level
6
0 = flash test omitted
1 = 3mA pass level
2 = 5mA pass level
8 = 3mA pass level up to 3 tests
4 = 5mA pass level up to 3 tests
7
0 = load test omitted
1 = 0.5kW pass level
2 = 1.0kW pass level
3 = 2.0kW pass level (230V) or 1.8kW (110V)
4 = 3.2kW pass level (230V) or 1.8kW (110V)
