5 Insulation test, pass limit
0 = Omit insulation test
1 = 2 M
Ω
2 = 4 M
Ω
3 = 7 M
Ω
4 = 1 M
Ω
5 = 0.5 M
Ω
6 Flash test voltage and pass limit selection
0 = Omit Flash test
1 = 1500V, 3mA
2 = 1500V, 5mA
3 = 3000V, 3mA
4 = 3000V, 5mA
7 Operation test, pass limit selection
0 = Omit Operation test
1 = 0.5 kVA
2 = 1.0 kVA
3 = 1.5 kVA
4 = 2.0 kVA
5 = 2.5 kVA
6 = 3.12 kVA
7 = 3.3 kVA
8
9
8 Earth Leakage test, pass limit selection
0 = Omit Earth leakage test
1 = 0.25mA
2 = 0.75mA
3 = 3.50mA
4 = 9.90mA (Top of range)
5 - 9 = N/A
A = 0.5 mA
B = 1.5 mA
G = 2.25 mA
9 Repeat Selection
0 = No repeat test
1 = Repeat Earth integrity
2 = Repeat Earth Integrity and insulation
3 = Repeat Earth Integrity and Flash
4 = Repeat Earth Integrity, Insulation and Flash
5 = Repeat Insulation
6 = Repeat Flash
7 = Repeat Insulation and Flash
8 - 9 = N/A
