By depressing the # key the display will move through each line of the test results,
holding the key down will cause the display to move rapidly through the test results.
The data will continue until all results have been displayed
To exit this stage press the ABORT key.
NOTE: When multiple tests have been performed the instrument will automatically
output the worst case.
SETTING COMPUTER AND PRINTER COMMUNICATIONS
At the PRESS # FOR NEW TEST prompt pressing the S key will allow the user to set
the baud rate and handshaking for interface to a computer or printer.
The user is presented first with the computer options and then the printer options.
For use with the PATS / PATS+ software the computer option should be set to
9600 / NONE, and the printer option to 1200 / none.
The settings are retained by the PAT2000i.
PRINTOUT FORMAT
NUMBER 0001 Test number auto increment
DATE 14-MAR-95 Set by operator
APP NO $$$$$$$$$$$ Any 10 character string
TEST MODE AUTO Selectable from AUTO / MAN / TEST
VISUAL CHECK P Visual check result
EARTH CURRENT 12A Test Current
EARTH XX.XXX OHM P Measured value + result
EARTH XX.XXX OHM P
EARTH XX.XXX OHM P
INS XXX.XX MEG P Measured value + result
INS XXX.XX MEG P
INS XXX.XX MEG P
FLASH X.XX mA P Measure value + result
FLASH X.XX mA P
FLASH X.XX mA P
LOAD XX.XX KVA P Measure value+result
LKGE X.XX mA P Measured value + result
LEAD CONTINUITY P Result
USER $$$$$$$$$$ User identity string
TEXT $$$$$$$$$$ Text entered by user up to
TEXT $$$$$$$$$$ 4 lines of 10 characters
TEXT $$$$$$$$$$
TEXT $$$$$$$$$$
TEXT $$$$$$$$$$ Earth Acceptable
PAT 2000i Portable Appliance Tester
