Operator
’
s Guide
Inspector 4000
™
002-5564
RJS, Minneapolis, MN
18
6.0 PCS Analysis
PCS Scanning (overview)
This section is an
overview
of PCS (print contrast signal) analysis.
When a
successful
scan is made, the “Good Read” LED will illuminate and a crisp chirp
or beep sound will be
emitted
.
Excellent results can be
obtained
when the auto-optic scan head is used properly. Make
sure the
bottom clear plastic plate
of the scanner is flat against the surface to be scanned.
This
will assure the proper scanning angle.
In addition to the
data
analysis screens you will also get a PCS analysis
screen
:
PCS 87 Req 75
Rmn 03% Rmx 90%
The top row of the display shows the calculated PCS. “Req” is the minimum PCS
required for the particular symbology.
The bottom row shows the minimum and maximum reflectance of the elements in the
symbol.
Rmx = maximum space reflectance (light)
Rmn = minimum bar reflectance (dark)
Note: The PCS is calculated as follows:
PCS = Rmx - Rmn
Rmx
