29243AC 35
SPECIFICATIONS
CAMERA SPECIFICATIONS
Model CM-511 Outdoor Speed Dome
Image Sensor 1/4” EXview CCD
Imaging DSP Sony Effio
IP Rating IP66
Type / Format NTSC
Wide Dynamic Range Yes
Minimum Illumination 0.01 Lux (B/W) / 0.1 Lux (Color), 50 IRE @ F1.6
Day / Night Yes (True Day Night)
Horizontal TVL 540 TVL
Service Monitor Jack No
S/N Ratio >50dB (AGC Off)
Focal Length F1.6, f 3.4 ~ 122.4 mm
Iris Control Auto / Manual
Synchronization Internal / Line Lock
Video Output 1.0 Vpp / 75Ω, BNC
White Balance Auto / Manual
Auto White Balance Range 2000 K - 10000 K
Backlight Compensation On / Off
Auto Gain Control Auto / Manual
Operating Temperature -49°F~ 122°F (-45°C ~ 50°C)
Heater Yes
Power Consumption 65W (Max)
Rated Amperage 2.71A
Input Voltage 24vAC ± 10%
Weight 5.7 lbs (2.6 kg)
Dimensions Ø7.4" (190mm) x H: 11.9" (302.5mm)
Housing / Dome Cover White / Clear
