20
DOME CABLE DEFINITION AND REQUIREMENTS
For operation, the integrated dome camera requires a video cable to carry the video signals to the remote
viewing site, a power cable to power the dome and an RS-485 data cable to carry commands from the control
device.
Cable Requirements
For operation, the integrated high speed dome cameras require video and data cables as described below:
•
The video cable sends video signals to a remote viewing site. Using a coaxial cable to send video signals
is recommended.
• RS-485 cable carries commands from a control device to the dome cameras. A CAT 5, 24 gauge cable is
recommended.
• The power cable provides AC 24V power supply to the dome.
Power Wire Length Specifications
Wire
Gauge
Maximum
Distance
22 27 feet
20 44 feet
18 69 feet
16 110 feet
14 175 feet
12 279 feet
10 444 feet
Note Ensure that the power supply corresponds with the dome’s power requirement, or product impairment
will occur. Contact a qualified maintenance engineer with any problems.
