PurePrecision Rotary Scales
IM-Mercury_II_PurePrecision_Scales Rev. 1 Page 3 ©2014 MicroE Systems
Mercury II PurePrecision Tape and Glass Scales
Installation Manual and Reference Guide
1.7 Standards Compliance
Mercury II models are CE and RoHS compliant.
1.8 Special Conventions Used
The following symbols are used throughout this document.
Symbol Description
Warning or caution: potential damage to scale.
Instructions show correct method.
Instructions show example of incorrect method.
2.0 PurePrecision Rotary Scales
For details on rotary scales, see the following:

Encoder data sheets

Encoder interface drawings
The following Tech Notes documents also contain information for using rotary scales.
Tech Note Description
Mercury Encoders: Design
Guidelines for Customer-Supplied
Hubs MicroE Systems offers standard hubs for each of our standard
rotary scales. Should customers want to design a hub themselves,
this document describes the key factors that should be incorporated
into the hubs.
Mercury Encoders: Alignment of
Rotary Scales This document describes two different methods of aligning rotary
scales: (1) optically centering the grating pattern track using a CCD
camera; and (2) using two sensors to “electrically” center the
grating.
Mercury Encoders: Design
Guidelines for Customer-Supplied
Rotary Scale Segment Holders This document provides design guidelines for customers who want
to design their own holders for rotary scale segments.
Go to the following MicroE Systems website to locate the listed Tech Notes:
http://www.microesystems.com/products/technical-notes-and-white-papers.
RoHS
