Features
• Compatible with SAE J1772 compliant Plug-In Electric Vehicles
• Status Indicator lights alert users to readiness and faults
• Supplies full charge in 3 – 6 hours
• 18' cord with cable hook for easy cord management
• Weatherproof NEMA 3R rating allows for indoor or outdoor installation
• Critical Safety Features
- Detects lack of ground (Ground Continuity Monitoring)
- Communication with vehicle confirms electrical connections prior to
charging
• Auto-reset allows charger to re-try after a minor electrical fault. This prevents
lock out and low charge situations.
• RoHs (Reduction of Hazardous Substances) Compliant
• Allows delayed start option for off-peak charging.
Specifications
Input Power 30A, 208/240VAC, 60Hz grounded
Output Power 30A, 208/240V
Charge Connector SAE J1772 Electric Vehicle Charge Connector
Charging Cord Length 18'
Enclosure
NEMA 3R Rating: rated for indoor or outdoor use,
protected against water, ice and dust
Operating Temperature -30°C to +50°C (-22°F to +122°F)
Storage Temperature -40°C to +80°C (-40F to +176°F)
Operating Voltage Range 85 to 265 VAC
Ground Fault Protection
Internal 20mA CCID (no external GFCI protection
required)
Standards & Certifications SAE J1772 Electric Vehicle Conductive Charge
Coupler Standard
UL2231-1 & 2 UL Standard for Personnel Protection
Systems for Electric Vehicle (EV) Supply Circuits
UL2251 UL Standard for Safety for Plugs,
Receptacles and Couplers for Electric Vehicles
UL2594 UL Outline of Investigation for Electric
Vehicle Supply Equipment
NEC Article 625 Electric Vehicle Charging System
UL 991 Test for Safety Related Controls Employing
Solid State Devices
UL 1998 Safety of Software in Programmable
Components
CSA C22.2 No. 107.1-01
For additional installation and operation information please visit our website:
www.legrand.us/passandseymour/evchargers.aspx
For technical support please contact us at (800) 223-4185 or
[email protected]
Limited One Year Warranty
Legrand/Pass & Seymour will remedy any defect in workmanship or material in Legrand/Pass &
Seymour products which may develop under proper and normal use within one year from date of
purchase by a customer:
(1) by repair or replacement, or, at Legrand/Pass & Seymour’s option, (2) by return of an amount equal
to consumer’s purchase price. Such remedy is IN LIEU OF ANY AND ALL EXPRESSED OR IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Such remedy by
Legrand/Pass & Seymour does not include or cover cost of labor for removal or reinstallation of the
product. ALL OTHER FURTHER ELEMENTS OF DAMAGE (INCIDENTAL OR CONSEQUENTIAL DAMAGES)
FOR BREACH OF ANY AND ALL EXPRESSED OR IMPLIED WARRANTIES INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXCLUDED HEREBY. (Some states
do not allow disclaimer or exclusion or limitation of incidental or consequential damages, so the above
disclaimers and limitation or exclusion may not apply to you.) ANY IMPLIED WARRANTIES INCLUDING
WHERE REQUIRED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
SHALL BE LIMITED TO THE ONE YEAR PERIOD SET FORTH ABOVE. (Some states do not allow limitations
on how long implied warranty lasts, so the above limitation may not apply to you.)
To insure safety, all repairs to Legrand/Pass & Seymour products must be made by Legrand/Pass &
Seymour, or under specific direction. Procedure to obtain performance of any warranty obligation is as
follows: (1) Contact Legrand/Pass & Seymour, Syracuse, New York 13221, for instructions concerning
return or repair; (2) return the product to Legrand/Pass & Seymour, postage paid, with your name and
address and a written description of the installation or use of the Legrand/Pass & Seymour product, and
the observed defects or failure to operate, or other claimed basis for dissatisfaction.
This warranty gives you specific legal rights and you may also have other rights which vary from state
to state.
