Legrand WC PK Preset Activation Kit with Extended Receptacle Bracket User Manual
Page 2
Power Feed from Center Compartment:
NOTE:
Install Receptacle Housing and Grommets as shown in the
current version of Installation Instruction 1 002 300.
1. Do not remove knockout in side of receptacle housing.
2.
Communications Bracket Series DTB-2EXT may only be used
on outboard cells designated for communication wiring, and
only with WPACREXT Series Receptacle Housings.
Wiremold
U.S. and International:
60 Woodlawn Street • West Hartford, CT 06110
1-800-621-0049 • FAX 860-232-2062 • Outside U.S.: 860-233-6251
Canada:
570 Applewood Crescent • Vaughan, Ontario L4K 4B4
1-800-723-5175 • FAX 905-738-9721
1 005 083R1 0310
© Copyright 2010 Legrand/Wiremold All Rights Reserved
