Programming a Sequence
Programming a Sequence
To program a sequence, proceed as follows:
1 Scan the bar code as shown in Figure 14 on page 14 .
2 Scan the bar codes one at a time in the order given in the following table.
Note: When scanning the bar codes in
Figure 2 on page 8 through Figure 14 on page 14 , it
may help to rotate them.
Scan Order
Profit Point Model
Profit Point PLUS
NT Profit Point
~ OR ~
DOS Profit Point
1 Figure 14 on page 14 Figure 14 on page 14
2 Figure 2 on page 8 Figure 2 on page 8
3 Figure 3 on page 8 Figure 4 on page 9
4 Figure 5 on page 9 Figure 6 on page 10
5 Figure 7 on page 10 Figure 8 on page 11
6 Figure 10 on page 12 Figure 9 on page 11
7 Figure 11 on page 12 Figure 10 on page 12
8 N/A Figure 12 on page 13
9 N/A Figure 13 on page 13
Each bar code has a page number in a note under it that corresponds to the hard copy page in
00-02407 Metrologic Instruments Inc. MetroSelect
® Configuration Guide included with the
scanner. If the bar code cannot be read from Figure 2 on page 8 through Figure 14 on page 14 ,
use the 00-02407 Configuration Guide.
Note: A PDF version of 00-02407 Metrologic Instruments, Inc. MetroSelect Configuration
Guide is available at the following URL:
ftp://ftp.metrologic.com/pub/download/productmanuals/00-02407.pdf
3 Exit the program mode by scanning in the bar code in Figure 14 on page 14 .
4 The scanner should now be properly programmed. Repeat the procedure in “Performing the
Verification Sequence” on page 6 to ensure proper programming.
Note: If the scanner does not work after following all the instructions listed above, it indicates
that the scanner may not be connected properly or the Profit Point POS terminal may
not be configured correctly. Repeat the procedure in “Setting Up the Scanner” on
page 5 . See the Hardware Configuration section in MDE-4356 Profit Point Reference
Manual to determine if the Profit Point POS terminal is configured correctly.
