Appendix

Install OS by using e-SATA

1. BIOS Setup

Before installing Operating System by using e-SATA device,you need to set the
BIOS setup first.

Step 1. Make sure the ‘Onboard e-SATA Device’in the ‘Advanced BIOS
Features’section is enabled.

Step 2. Select the e-SATA Mode.
If you select [IDE] in “e-SATA Mode Select” then no other special steps required for
installing OS.
If you select [AHCI] in “e-SATA Mode Select” ,please follow the below instructions
in ”2.Installing setup(AHCI Mode)”

Step 3. Save and exit the BIOS setup,correct connecting the e-SATA device before
reboot you PC.

2. Installing Setup(AHCI Mode)

Step 1. Create e-SATA Driver Floppy.

Please refer to the’’Bootable RAID Array”in

page 62.

Note:

AHCI Mode support SATAII NCQ,better performance.
