Chapter 2 Installation Instructions

Other Connectors

This motherboard includes connectors for FDD device, IDE device,Serial ATA
devices, USB devices, IR module, and others.

FDD Connector: FLOPPY
This motherboard includes a standard FDD connector, supporting 360K, 720K,
1.2M, 1.44M, and 2.88M FDDs.

IDE Connectors: PIDE
These connectors support the provided UltraDMA133/100/66 IDE hard disk rib-
bon cable and you can configure as a disk array through RAID controller. Refer
to RAID manual (in CD) for details on how to set up RAID configurations.

Front Panel Connector: FP1
This motherboard includes one connector for connecting the front panel switch
and LED indicators.

Hard Disk LED Connector (HDD-LED)
The connector connects to the case’s IDE indicator LED indicating the activity
status of hard disks.

Reset Switch (RESET)
Attach the connector to the Reset switch on the front panel of the case; the
system will restart when the switch is pressed.

Power LED Connector (PWRLED)
Attach the connector to the power LED on the front panel of the case. The Power
LED indicates the system’s status. When the system is in S0 status, the LED is
on. When the system is in S1 status, the LED is blink; When the system is in S3,
S4, S5 status, the LED is off.

Attention:

If you install two IDE device, you must configure the second drive
as a slave device.
