Advanced BIOS Features
► IDE Configuration/ACHI Configuration/MPS Configuration
Press
IDE Configuration
► Configure SATA as
This item is used to set the operation mode of your SATA ports 1, 2, 3, 4, 5, 6. Setting values
are: [IDE]; [RAID]; [AHCI]; [Disabled].
[IDE] - This configures the SATA ports to support IDE mode.
[RAID] - When you enable RAID, it means all your SATA drives must also support AHCI.
[AHCI] - The Advanced Host Controller Interface (AHCI) specification describes the register
level interface for a Host Controller for Serial ATA. The specification includes a description of
the hardware/software interface between system software and the host controller hardware.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Advanced BIOS Features
Advanced Settings
Help Item
► IDE configuration
Press Enter
Configure the IDE
► AHCI Configuration
Press Enter
device(s).
► MPS Configuration
Press Enter
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
Press Enter
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
IDE Configuration
IDE Configuration
Help Item
Configure SATA as
IDE
SATA#1 IDE Configuration Compatible
SATA#2 IDE Configuration Enhanced
IDE
RAID
► Primary IDE Master
Not Detected
AHCI
► Primary IDE Slave
Not Detected
Disabled
► Secondary IDE Master
Not Detected
► Secondary IDE Slave
Not Detected
► Third IDE Master
Not Detected
► Fourth IDE Master
Not Detected
Hard Disk Write Protect
Disabled
IDE Detect Time Out
35
ATA(PI) 80Pin Cable Detect Host & Device
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
Options
IDE
