5
110
2. Copy section 5-2, BIOS Configuration.
Shut down the computer, connect SATA hard disks to SATA ports, power on
computer again.
Press key, get into BIOS, set "SATA Mode" to [RAID], press to save
and exit BIOS. PC will reboot.
3. Copy section 5-3, Create RAID in BIOS.
Press simultaneously to get into RAID BIOS set up (Intel ® Matrix Stor-
age Manager utility).
Configure your new hard disks to RAID0, 1, 5 or 10. Exit RAID BIOS. PC will reboot.
4. The Windows XP is running again and a new hardware of RAID disk was found.
Click [Cancel] to skip this Wizard.
Click to exit.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
IDE Configuration
IDE Configuration Help Item
Configure SATA as
SATA#1 IDE Configuration Compatible
SATA#2 IDE Configuration Enhanced IDE
RAID
► Primary IDE Master Not Detected AHCI
► Primary IDE Slave Not Detected Disabled
► Secondary IDE Master Not Detected
► Secondary IDE Slave Not Detected
► Third IDE Master Not Detected
► Fourth IDE Master Not Detected
Hard Disk Write Protect Disabled
IDE Detect Time Out 35
ATA(PI) 80Pin Cable Detect Host & Device
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
Options RAID
