4. It then goes to “ Disks” item. Press to display the hard disks list for this
Recovery system.
5. From the hard drive list, use Up or Down arrow key to reach the hard disks you want
to combine them as Recovery, then press key to select Master disk and press
key to select Recovery disk. Here, we select 298.0GB as Recovery disk
and 74.5GB as Master disk. Press key to finish the selection.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
Intel(R) Matrix Storage Manager option ROM v8.9.0.1023 PCH-D wRAID5
Copyright(C) 2003-09 Intel Corporation. All Rights Reserved.
Name:
RAID Level:
TryRecovery
Recovery
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
Port Drive Model Serial # Size Status
0 Maxtor STM332082 6QF4CRAW 298.0GB Non-RAID Disk
2 WDC WD1500ADFD-0 WD-WMAP42036047 139.7GB Non-RAID Disk
3 WDC WD800AAJS-00 WD-WMAP95242993 74.5GB Non-RAID Disk
4 WDC WD3200AAKS-0 WD-WCARW4154961 298.0GB Non-RAID Disk
Select 1 Master and 1 Recovery disk to create volume.
[↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done
