exit RAID bIoS

1. Take TryRAID5 as an example, select “

5. exit” in main menu and press .

The screen displays :

2. Press to exit Intel

®

Matrix Storage Manager program. The system will reboot.

3. Shut down the computer, remove the Non-RAID disk, and we will continue for

Windows OS installation. If you do not remove irrelevant hard disk, Windows may
detect it during the installation, and you could be confused.

4. Remove any diskette from floppy drive.
5. Restart computer to start Windows installation.

Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5

Copyright(C) 2003-04 Intel Corporation All Rights Reserved.

1. Create RAID Volume

3. Reset Disks to Non-RAID

2. Delete RAID Volume

4. Recovery Volume Options

5. Exit

RAID Volume :

ID

Name

Level Stripe Size

Status Bootable

0

TryRAID5

RAID5(Parity) 64KB 149.1GB

Normal

Yes

Physical Disks:

Port Drive Model

Serial #

Size

Type/Status(Vol ID)

0

Maxtor STM332082 6QF4CRAW

298.0GB

Member Disk(0)

2

WDC WD1500ADFD-0 WD-WMAP42036047 139.7GB

Member Disk(0)

3

WDC WD800AAJS-00 WD-WMAP95242993 74.5GB

Member Disk(0)

4

WDC WD3200AAKS-0 WD-WCARW4154961 298.0GB

Non-RAID Disk

[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu

Intel(R) Matrix Storage Manager option ROM v8.9.0.1023 PCH-D wRAID5

Copyright(C) 2003-09 Intel Corporation. All Rights Reserved.

[

DISK/VOLUME INFORMATION

]

[

MAIN MENU

]

3. Reset Disks to Non-RAID

Are you sure you want to exit? (Y/N):

[

CONFIRM EXIT

]
