Create Recovery

1. Select “

1.Create RAID Volume” from the main menu and press .

2. In "

Name" item, you can input a device name for the Recovery system and press

to apply it. Here, we name it as TryRecovery to replace the default Volume0.

3. In “

RAID Level” item, you can use Up or Down arrow key to make a selection.

Select Recovery and press .

Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5

Enter a unique volume name that has no special characters and is

16 characters or less.

Intel(R) Matrix Storage Manager option ROM v8.9.0.1023 PCH-D wRAID5

[

CREATE VOLUME MENU

]

[

HELP

]

Name:

RAID Level:

Disks:

Strip Size:

Capacity:

Sync:

Volume0

RAID0(Stripe)

Select Disks

128KB

0.0 GB

N/A

Create Volume

TryRecovery

[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select

Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5

Choose the RAID level:

RAID 0: Stripes data (performance).

RAID1: Mirrors data (redundancy).

Recovery: Copies data between a master and a recovery disk.

RAID 10: Mirrors data and stripes the mirror.

RAID 5: Stripes data and parity.
