To change the fold positions press the button next to a fold. Enter the required position
of the relevant fold.
Maximum position Minimum position Fold type
Longest document
length minus 25 mm
(0.98") 75 mm (2.95") V-fold
Longest document
length minus 50 mm
(1.97") 75 mm (2.95") First fold C-fold
Longest document
length minus 25 mm
(0.98") Position first fold plus
25 mm (0.98") Second fold
Longest document
length minus 100 mm
(3.94") 75 mm (2.95") First fold Z-fold
Longest document
length minus 75 mm
(2.95") Position first fold plus
25 mm (0.98") Second fold
Longest document
length minus 50 mm
(1.97") 75 mm (2.95") First fold Double V-fold
Longest document
length minus 25 mm
(0.98") Position first fold plus
25 mm (0.98") Second fold
The touch screen will indicate when entered positions are out of
range.
