Maintenance and Troubleshooting
4-17
Modem/Radio Interface J-box, signal converter 0A-1279-0168
Cables:
Cable; 18” RJ11; 6-Cond.,Straight 0A-1137-0160
Cable; RJ45, 8-Cond. M-M, Straight, 18” 0A-1229-0054
Cable; 10ft, RJ45, 4 pair twisted/Black W-1383
Cable; 20ft, RJ45, 4 pair twisted 24 AWG W-1406
Cable Assy; 20 pos. Ribbon 18”, Dual Row W-1387
Ribbon Assy; 20 pos, 30” 0A-1000-0017
Ribbon Assy; 20 pos, 36” 0A-1000-0018
Ribbon Assy; 20 pos, 60” 0A-1000-0021
Cable; 22 AWG (Light Sensor/Temp Sensor to Controller) W-1234
Cable; 10-pin male to 10-pin male, 4’, QC (PS to S) W-1483
Cable; 10-pin male to 10-pin male, 10’, QC (PS to S) W-1500
Cable; 31-pin male to 31-pin male, 6’, Interconnect (PM to M) W-1503
Quick Connect Interface, Input 0P-1229-2001
Quick Connect Interface, Output 0P-1229-2002
Primary/Mirror 31-pin QC Interface 0P-1229-2008
Power Supply W/Harness; (3 Red) (1, A-1633) 0A-1213-2039
Power Supply w/Harness; (4 Amber) (2, A-1555) 0A-1213-2043
Power Supply w/Harness; (4 Amber) (1, A-1555) 0A-1213-2012
Power Supply w/Harness; (Red/Green) (1,A-1633,1,A-1591) 0A-1213-2042
Electrical Contact Cleaner Lubricant / Cal-Lube CH-1019
Hex Wrench, T-Handle 1/8” RT TH-1062
Manual; Venus 1500 Operator’s, Version 3.0 ED-13530
Manual; Venus 1500 Radio, Gen 2 ED-13932
4.12 Daktronics Exchange and Repair and Return
Programs
To serve customers' repair and maintenance needs, Daktronics offers both an
Exchange Program and a Repair and Return Program.
Daktronics' unique Exchange Program is a quick, economical service for replacing
key components in need of repair. If a component fails, Daktronics sends the
customer a replacement, and the customer, in turn, sends the failed component to
Daktronics. This not only saves money, but also decreases display downtime.
Daktronics provides these plans to ensure users get the most from their Daktronics
products, and it offers the service to qualified customers who follow the program
guidelines explained below. Please call the Help Desk – 877-605-1113 – if you have
questions regarding the Exchange Program or any other Daktronics service.
When you call the Help Desk, a trained service technician will work with you to
solve the equipment problem. You will work together to diagnose the problem and
determine which replacement part to ship. If, after you make the exchange, the
equipment still causes problems, please contact our Help Desk immediately.
