Maintenance and Troubleshooting 4-16
4.10 Initialization Operation Information
Every time the display is operated, the display will run through an initialization in
which it will display the following:
1. Product Name (Galaxy®)
2. Display Size (Row x Column)
3. Shading (32K RGB)
4. Bootloader Version (OS X.XX)
5. Firmware Number (ED13305)
6. Firmware Revision (Rev X.XX)
7. Hardware Address (HW:XX)
8. Software Address (SW:XX)
9. IP Address: (172.16.192.25)
10. Subnet Msk: (255.255.0.0)
11. COM1 Configuration (C1:V15) ((Modem C1:V15) If a Modem is present)
12. Line Frequency (CLK:60 Hz)
13. Display Name Description
4.11 Replacement Parts List
The following tables contain some of the items that may need to be replaced in these
displays over a period of time. Many of the parts within the display also list their part
numbers on labels affixed to them.
To prevent theft Daktronics recommends purchasing a lockable cabinet to store
manuals and replacement/spare parts.
Part Description Part Number
Controller Galaxy 8 Conn 0A-1229-0005
Module, 3R (1:1) 8x8 (30x70) 0A-1208-3006
Module, 4A (1:1) 8x8 (30x70) 0A-1208-3005
Module, 2R, 2G (1:1) 8x8 (30x70) Type 3 0A-1208-2504
Thermostat Enclosure 85-70-9L 0A-1213-4024
Digital Light Sensor 0P-1247-0003
Digital Temperature Sensor 0P-1247-0007
Filter; Air, Gasket, 7.50” x 13.50” x .88” EN-1774
Fan; 110CFM, 120VAC, (B-1006) (8,16, and 24 high) 0A-1213-4014
Fan; 245CFM, 120VAC, (B-1019) (32,40, and 48 high) 0A-1213-4010
Transformer; Pri 115V, Sec 10VCT, 3Amp (120V Displays) T-1119
Filter, RFI Line 10 AMP 120 VAC Z-1007
Modem Board; 232 Coated 0P-1279-0003
Fiber Board; RS232 to Fiber, 12V 0P-1127-0024
Surge Suppression Board, RS422 0P-1146-0031
Signal Converter (RS232/RS422) 0A-1127-0237
Signal Converter (RS232/Fiber) 0A-1127-0239
Outdoor Client Radio Interface, QC, Gen 2 0A-1146-0078
Outdoor Server Radio Interface, QC, Gen 2 0A-1146-0079
Radio TX Interface J-box, signal converter 0A-1279-0161
