- D 63 -
Short Seam Automat 2110-4 / 2111-4 Workinging Instructions
Beisler Automated Sewing Equipment
D.3
Programming
D.3.1 System menu
The system menu is divided into several submenus. The
submenus themselves are divided into access-protected
and open submenus. Access is protected by the service
code.
Open submenus
Open submenus are freely accessible from the start menu:
•
Enter service code,
•
Clamp motor step test
•
Display total piece counter
Access-protected submenus
Access-protected submenus can only be opened after the
service code has been entered:
•
Eprom seam parameters
•
Copy seam numbers
•
Erase seams
•
Enter seam name
•
Copy sewing program to memory card
•
Load sewing program from memory card
•
Copy variables (global parameters/special parameters)
to memory card
•
Load variables (global parameters/special parameters)
from memory card
•
Run clamp motor in permanent test
•
Test thread cutter
•
Test stacker
•
Enter mechanic code
NOTE - System menu control!
The submenus of the system menu are requested and
exited using the same keys. Exceptions from this rule are
indicated by plain text in the corresponding menu.
Request the system menu from the start level:
•
Press
key.
Confirm input and exit the system menu:
•
Press
key.
NOTE - Submenu levels!
All input for the system menus must be started from the
submenu level (1).
To change to the submenu level (1):
•
Press
0 key.
The submenus of the system menu can be requested
using either the arrow keys or the function keys.
NOTE - RESET!
As a rule, a RESET should be performed in the system
menu after settings have been changed to reset the ma-
chine to its start position.
•
Press program stop key, then unlock key.
Entering the service code:
Entering the service code allows access to the access-
protected submenus of the system menu.
•
Press
key
•
Press
key (service code).
•
Enter service code numbers using the numeric keypad.
The code is: 50190
•
Press
key to confirm input.
Testing clamp motor steps:
This diagnostic function is used to test the function of the
clamp motor sensor interface.
•
Press
key
•
Press
key (diagnostics).
•
Press
key (clamp transport).
•
Press
key (clamp motor steps).
