Short Seam Automat 2110-4 / 2111-4 Working Instructions
- C 54 -
Beisler Automated Sewing Equipment
C.6
Troubleshooting
Error 32:
„Thread position does not
come“ During thread cutting, sewing motor did not
reach cutting position Input slower cutting speed and earlier
cutting position; replace sewing motor or
synchronizer
Error 33:
„Sewing motor does not
stop“ After thread cutting, sewing motor does not
stop within error period Input slower cutting speed and earlier
cutting position; replace sewing motor or
synchronizer
Error 34:
„Needle not up“ Needle not in upper rest position; when the
error message is issued, the control unit
attempts once more to move the needle to
the upper position Check sewing motor and synchronizer;
check connection between 9020013 and
sewing motor; read condition of two upper
LEDs at 9020013: if no LED illuminates
when handwheel is rotated, check sewing
motor power supply; replace sewing motor
if required; if LEDs are OK, check
connection between 9020020 and sewing
motor; replace 9020020 if required
Error 35:
„Thread breakage“ Thread monitor detects thread breakage
Error 37:
„Thread only rest“ The photocell at the spool case is
illuminated, spool empty If spool is not empty, the photocell is
maladjusted (response too sensible); adjust
correctly
Error 41:
„No parts“ Photocell FZ21 remains illuminated during
insertion Adjust photocell sensibility; input test 21
Error 42:
„Photocell not lighted“ Photocell FZ21 does not detect end of
seam Sewing distance too long; adjust photocell
sensibility; input test 21
Error 43:
„Photocell lighted too early“ Photocell FZ21 detects intermittent
reflection during insertion Adjust photocell sensibility; input test 21
Error 45 ... 48:
“I/O DAC, ULN, 485, RES” Internal hardware error during data
transmission to adapter board 9020020 Replace 9020020
