AMETEK XHR 1000 Watt Series User Manual
Page 24
Features and Specifications
Specifications
24
Operating Manual for XHR Series Power Supply
Table 1.2 Electrical Specifications for 7.5 V to 40 V Models
Models
7.5-130
20-50
33-33
40-25
Output Ratings:
Output Voltage
Output Current
Output Power
At the front panel binding posts:
Output Current
Output Power
0-7.5 V
0-130 A
975 W
0-30 A
225 W
0-20 V
0-50 A
1000 W
0-30 A
600 W
0-33 V
0-33 A
1089 W
0-30A
990 W
0-40 V
0-25 A
1000 W
Line Regulation:
1
Voltage (0.01% of Vmax + 2 mV)
Current (0.01% of Imax + 1 mA)
3 mV
14 mA
4 mV
6 mA
5 mV
4.3 mA
8 mV
2.8 mA
Load Regulation:
2
Voltage (0.01% of Vmax + 2 mV)
Current (0.05% of Imax + 1 mA)
At the front panel binding posts:
Voltage
3 mV
66 mA
650 mV
4 mV
26 mA
650 mV
5 mV
18 mA
650 mV
6 mV
14 mA
500 mV
Meter Accuracy:
Voltage (1% of Vmax + 1 count)
Current (1% of Imax + 1 count)
0.09 V
1.4 A
0.3 V
0.6 A
0.43 V
0.43 A
0.5 V
0.35 A
Output Noise and Ripple (V):
rms
p-p (0-20 MHz)
At the front panel binding posts:
p-p (0-20 MHz)
10 mV
70 mV
250 mV
10 mV
70 mV
250 mV
7.5 mV
75 mV
350 mV
7.5 mV
75 mV
350 mV
Drift (8 hours):
3
Voltage (0.05% of Vmax)
Current (0.1% of Imax)
3.75 mV
130 mA
10 mV
50 mA
16.5 mV
33 mA
20 mV
25 mA
Temperature Coefficient:
4
Voltage (0.02% of Vmax/°C)
Current (0.03% of Imax/°C)
1.5 mV
39 mA
4 mV
15 mA
6.6 mV
9.9 mA
8 mV
7.5 mA
Maximum Remote Sense
Line Drop Compensation
5
3 V/line
5 V/line
5 V/line
5 V/line
OVP Adjustment Range:
(5% to 110% of Vmax)
0.375-8.25 V
1-22 V
1.65-36.3 V
2-44 V
Efficiency
6
81%
83%
83%
83%
1. For input voltage variation over the AC input voltage range, with constant rated load.
2. For 0-100% load variation, with constant nominal line voltage. Measured at the rear panel output connector unless
stated otherwise.
3. Maximum drift over 8 hours with constant line, load, and temperature, after 30-minute warm-up.
4. Change in output per °C change in ambient temperature, with constant line and load.
5. Line drop is subtracted from total voltage available at supply output.
6. Typical efficiency at 115 Vac input and rated output power.
