Remote Operation
4-2 TM-F2OP-C1XN-01
Introduction
The rear panel switches and connector on the power supply allow you to
program the supply with an analog device or to output readback signals.
This section covers the following topics:
• See “Remote Analog Programming of Output Voltage and Current
Limit” on page 4–3 for information about remote analog
programming of output voltage and current limit with 0-5 V and
0-10 V voltage sources and 0-5 k and 0-10 k resistances.
• See “Remote Monitoring of Output Voltage and Current” on page 4–7
for the connector and switch settings when using calibrated readback
signals for output voltage and output current with selectable 0-5 V or
0-10 V scales.
Isolated Programming
The four-channel Isolated (ISOL) Programming Interface is an internal
card which is ordered as an option. It allows remote programming and
readback of the power supply’s output voltage and current limit with 0-5V
analog signals at a different potential relative to the power supply’s
output. Contact the manufacturer to order.
Remote Digital Programming
You can operate the power supply from a computer if you have had the
GPIB or RS-232 Interface card installed as an option. Refer to the
separate interface manual for all setup and operation instructions for
remote digital programming.
