Installation
2-6 TM-F2OP-C1XN-01
AC Input Connector and Voltage Selection
The AC input connector is a 3-terminal wire clamp located on the power
supply’s rear panel. See Figure 2-2 on page 2–8. See Table 2-2 for the
input voltage ranges and frequency required to operate the power supply.
AC Fail LED The AC Fail (ACF) LED turns on when the input voltage
is outside of the range specified for the power supply. The LED turns off
when the input voltage is within the range.
AC Input Cord
The AC input cord we recommend is specified in Table 2-3. Add a non-
locking plug suitable for use in the country in which you are operating. If
you require a special cord, call us.
Table 2-2 Operation AC Input Voltage Range and Frequency
AC Voltage Range Frequency
190-264 Vac 1 φ
(24.3 A maximum at 208 Vac; 22.4 A maximum at 230 Vac)
47-63 Hz
WARNING
The AC input cord is the disconnect device for the power supply. The plug must
be readily identifiable by and accessible to the operator. The input cord must be
no longer than 9.84 feet (3 m).
Table 2-3 AC Wire Specification
Wire Size Ratings Cable Outside Diameter
3 x 12 AWG stranded
copper 60 °C minimum,
300 V 0.545-0.708 in.
(13.63-17.7 mm)
