Dukane Projector 976SX - Manual (Page 21)

21
Status Monitor
 In error state
The Status Monitor displays a warning of an error
with larger letters. Resolve the errors referring to the
table of the sections " Related messages" (119) and
" Regarding the indicator lamps" (120, 121) when the
warning is displayed.
Displayed warnings are as below;
COVER: The lamp cover has not been properly fixed.
Refer to the LAMP indicator blinking in the table (120).
FAN: The cooing fan is not operating.
Refer to the TEMP indicator blinking in the table (121).
LAMP: The lamp does not light.
Refer to the LAMP indicator lighting in the table (120).
TEMP: The projector's interior becomes over heated.
Refer to the TEMP indicator lighting in the table (121).
AIR (AIR FLOW): The internal temperature is rising.
Refer to the description of the message, "CHECK THE AIR FLOW" in the
table (119).
COLD: There is a possibility that the interior portion has become over cooled.
Refer to the LAMP and TEMP indicators alternatively blinking in the table
(121).
FILTR (FILTER): It is time to clean the air filter.
Refer to the LAMP and TEMP indicators simultaneous blinking in the table
(121).
• When one of the warnings of FAN, LAMP, COVER, TEMP errors is
displayed, the backlight blinks at the same time.
NOTE
Displaying the condition of the projector (continued)
: Displays supplied voltage and peripheral temperature in Celsius
while the lamp is on.
3rd line
• While the projector is searching an input signal or USB TYPE A ports
are selected in normal condition, nothing is displayed on the 2nd line of the
monitor.
• When the USB TYPE B port is selected even if MOUSE is selected in the
USB TYPE B item of the OPTION menu, "NO SIGNAL" is displayed on the 2nd
line of the monitor (67).
• Displayed temperature might differ from actual peripheral temperature
because the displayed temperature is measured inside of the projector.
NOTE
example
O R C E V
