Dell Manager 193
SCSI Channel
Choose Objects—> SCSI Channel to select a SCSI channel on a controller.
Table 12-7 displays the operations you can perform on the selected channel.
Battery Backup
Choose Objects-> Battery Backup to view the battery backup information.
You can use the battery backup menu to reset the charge cycle count. Table
12-8 displays the menu items.
Ta b l e 1 2 - 7 . S C S I C h a n n e l O p t i o n s
Option Description
State Choose this option to enable termination.
Termination Choose this option to set the type of termination.
Ta b l e 1 2 - 8 . B a t t e r y B a c k u p M e n u I t e m s
Menu Item Explanation
Backup
Module
PRESENT will appear if there is a battery module; ABSENT if
there is not.
Battery Pack PRESENT will appear if the battery pack is properly installed;
ABSENT if it is not.
Temperature GOOD appears if the temperature is within the normal range.
HIGH appears if the module is too hot.
Voltage GOOD appears if the voltage is within the normal range. BAD
appears if the voltage is out of range.
Fast Charging COMPLETED appears if the fast charge cycle is done.
CHARGING appears if the battery pack is charging.
