184 PERC 3 BIOS Configuration Utility
w
w
w
.d
e
ll
.co
m
|
s
u
p
p
o
rt
.d
e
ll.c
o
m 10 Press to exit the Advanced Menu.
You are prompted to accept the settings.
11 Highlight Accept and press .
Do not initialize the logical drive.
12 Press . and choose Yes at the Save prompt.
13 Exit the BIOS Configuration Utility.
14 Reboot the system.
15 Set the host system to boot from SCSI, if such a setting is available.
Exiting the PERC 3 BIOS
Configuration Utility
Perform the following steps to exit the BIOS Configuration Utility.
1 Press when the Management Menu displays.
2 Choose Yes at the prompt.
3 Reboot the computer.
The PERC 3 BIOS message appears again.
4 Press when the BIOS Configuration Utility prompt appears.
Setting Hardware Termination
If you are using the PERC 3/DC for clustering, you must use hardware
termination. Otherwise, software termination may be used. The headers
used for SCSI termination are:
• J2 Termination Enable is a three-pin header that specifies control of
the SCSI termination for channel 0.
• J3 Termination Enable is a three-pin header that specifies control of
the SCSI termination for channel 1.
• J5 Termination Enable is a three-pin header that specifies control of
the SCSI termination for channel 2.
• J7 Termination Enable is a three-pin header that specifies control of
the SCSI termination for channel 3.
