112 PERC 3/SC Hardware Installation
w
w
w
.d
e
ll
.co
m
|
s
u
p
p
o
rt
.d
e
ll.c
o
m
Insert the PERC 3/SC card in a PCI slot, as shown in Figure 8-5. Screw the
bracket to the computer chassis.
F i g u r e 8 - 5 . I n s t a l l a t i o n o f P E R C 3 / S C C a r d i n t o
M o t h e r b o a r d
32-bit Slots
64-bit Slots
(3.3 V)
(5 V)
Edge of
Mother Board
Bracket Screw
